A reliable 9L water fire extinguisher designed for Class A fires involving solid combustibles such as wood, paper, textiles, and other organic materials. Not suitable for electrical fires.
REF. 001/0034
Sharing is the key to unlocking a world of possibilities!
The ReActive 9L Water Fire Extinguisher is designed specifically for Class A fires involving solid combustibles such as wood, paper, textiles, straw, and similar organic materials. Its powerful water jet provides effective flame cooling and penetration, making it ideal for schools, warehouses, workshops, offices, and general commercial environments.
This extinguisher must not be used on electrical fires. Water is a highly conductive agent and may increase the risk of injury when applied to energised equipment.
| Specifications | |
|---|---|
| Height | 580mm |
| Diameter | 175mm |
| Mass Empty | 3.9kg |
| Mass Full | 12.9kg |
| Discharge Time | >12sec |
| Effective Range | 3–12m |
| Discharge Nozzle | Hose & Horn |
| Working Temperature | -15°C to +60°C |
| Working Pressure | 1400kPa |
| Test Pressure | >2100kPa |
| Burst Pressure | >5500kPa |
| Safety Device | ±2200kPa |
| Neck Ring Thread | M30 × 1.5 |
| Pressure Indicator | Ø23 M10 × 1.0 |
| Outlet Thread | G ¼" × 19 |
| Syphon Tube | M16 × 1.5 |
| Construction Details | |
|---|---|
| Construction | Deep draw mild steel cylinder (welded neck & base) |
| Brass Specification | CZ122 Die Forging Brass (HPB59-1) |
| Body | Forged & Nickel plated |
| Discharge Hose | EN694 PVC hose, 545–580mm length |
| Cylinder Finish | Red epoxy powder coated |
| Inner Lining | PPA coated for corrosion resistance |
